| Size | D | Tolerance | t(min) | Tolerance | D1 |
| 1/2" | 21.34 | 0.1 | 3.73 | 0.51 | 15.76 |
| 3/4" | 26.67 | 0.1 | 3.91 | 0.51 | 20.96 |
| 1" | 33.4 | 0.13 | 4.55 | 0.53 | 26.64 |
| 1-1/4" | 42.16 | 0.13 | 4.85 | 0.58 | 35.08 |
| 1-1/2" | 48.26 | 0.15 | 5.08 | 0.61 | 40.94 |
| 2" | 60.33 | 0.15 | 5.54 | 0.66 | 52.48 |
| 2-1/2" | 73.03 | 0.18 | 7.01 | 0.84 | 62.68 |
| 3" | 88.9 | 0.2 | 7.62 | 0.91 | 77.92 |
| 4" | 114.3 | 0.23 | 8.56 | 1.02 | 102.26 |
| 5" | 141.3 | 0.25 | 9.52 | 1.14 | 128.2 |
| 6" | 168.28 | 0.28 | 10.97 | 1.32 | 154.08 |
| 8" | 219.08 | 0.38 | 12.7 | 1.52 | 202.74 |
| 10" | 273.05 | 0.38 | 15.06 | 1.8 | 254.51 |
| 12" | 323.85 | 0.38 | 17.45 | 2.08 | 303.23 |
| 14" | 355.6 | 0.38 | 19.05 | 2.29 | 333.4 |
| 16" | 406.4 | 0.48 | 21.41 | 2.57 | 381 |
| 18" | 457.2 | 0.48 | 23.8 | 2.84 | 428.66 |
| 20" | 508 | 0.58 | 26.19 | 3.15 | 477.34 |
| 24" | 609.6 | 0.79 | 30.94 | 3.17 | 574.7 |
